Best of Both Worlds
The strength of the titanium, the aesthetic of your art.
Panthera Fusion BarTM
Introducing the first splitting protocol on the market that allows in-lab milling of the overlay while Panthera manufactures the implant bar. Unrivaled strength and durability for your restoration in Zirconia, PMMA, or any other material. It’s a fusion of a unique low-profile implant bar with a seamless, synchronized workflow. It’s the PFBTM effect.
Features
|
|
 |
|---|
- Engineered shape, form and function based on dental science
- Implant compatibilities: 700+ analog / 130+ digital workflow
- Splitting files made easy / Ready to mill .STL overlay
Bar Profile Benefits
- Low-Profile Implant Bar
No bone reduction needed. - Rounded Angle at the top of the bar
Avoid pressures points. - Chamfer Buccal Seating at 10°
Guarantee a perfect seating position with all the hygiene benefits. - Adaptative Bar Design
Design of the bar will always follow your soft tissues, setup and implant position. - 90° Lingual Seating
Perpendicular with the occlusal plane. - Constant Cement Space
Cement gap is always constant and within the bar profile.
Overlay Benefits
- Splitting Protocol
The implant bar and overlay splitting protocol ensures a straight milling line without undercut that facilitate your production and insertion. The cement gap is controlled on the bar and not on the overlay. - Your Setup As Is
Panthera’s proprietary technology ensures that every detail of your final setup (physical or digital) is preserved for an exact copy. - Your Overlay Material – Your Choice
Temporary or final prosthesis. Zirconia or printed or milled PMMA. The choice is yours. You can even let Panthera mill it for you.
Bar Profile Benefits
- Low-Profile Implant Bar (around 8mm)
No bone reduction needed. - Rounded Angle at the op of the bar
Avoid pressures points. - Chamfer Buccal Seating at 10°
Guarantee a perfect seating position with all the hygiene benefits. - Adaptative Bar Design
Design of the bar will always follow your soft tissues, setup and implant position. - 90° Lingual Seating
Perpendicular with the occlusal plane. - Constant Cement Space
Cement gap is always constant and within the bar profile.
Overlay Benefits
- Splitting Protocol
The implant bar and overlay splitting protocol ensures a straight milling line without undercut that facilitate your production and insertion. The cement gap is controlled on the bar and not on the overlay. - Your Setup As Is
Panthera’s proprietary technology ensures that all details you have made in your final setup (physical or digital) are kept for an exact copy. - Your Overlay Material – Your Choice
Some will use zirconia, others will print or mill PMMA. You can even let Panthera mill it for you. The choice is yours.
Ready to work on your overlay under 72 hours
Panthera design your bar
You approve the design
You receive the .STL of the overlay, ready to be milled in your lab
Panthera splits the file in two:
– Panthera Fusion Bar (milled by Panthera)
– Overlay (milled in your lab)
The art of synchronization: Panthera mill the implant bar while you characterize your overlay
You characterize your overlay
You assemble the overlay on the implant bar, and voila! You have your final restoration!
Panthera mill the implant bar
How to work with Panthera
|
|
|
